China Gate Valve Features



China Gate Valves Metal Sealed Types Of Gate Valves Sealing surface wear-resistant carbide, wear resistance, good sealing, long service life. When the gas source from the intake port access, the cylinder rod drives the valve plate to move downward, the valve closed.


China Gate Valves application


China Gate Valves Metal Sealed Types Of Gate Valves Mainly used in power plants, metallurgy, medicine, chemicals, water, heating, and other types of dust, particle transport.Good sealing performance. Fully open when the sealing surface erosion by smaller.


Nominal Diameter:        DN50–DN600

Nominal Pressure:       10Bar/16Bar

Design Standard:         MSS SP-70/BS5150/BS5163/DIN3352/JIS B2043

FTF Dimension:            ANSI B16.10/BS5150 SERIES 3/DIN3302 F4/JIS B2002

Flange Connection:     ASME B16.1 CL125/ASME B16.5 CL150/

                                       DIN 2501 PN10-16/EN1092 PN10-16 /JIS B2212 10K

Inspection and Test:    ISO 5208/EN 12266-1/ API598

Material List:


No. Item                            Material                Symbol

1Body/Bonnet                 Cast Iron                    ASTM A126 CLB/JIS G 5501 FC20

2. Wedge                         Cast Iron                    ASTM A126 CLB/JIS G 5501 FC20

3. Stem                            Stainless Steel      JIS SUS420J1

4. Seat                             Cast Bronze          ASTM B62/JIS G 5511 BC6

5. Wedge Face Rings      Cast Bronze          ASTM B62/JIS G 5511 BC7

6. Handwheel                   Cast Iron               ASTM A126 CLB/JIS G 5501 FC20

7. Packing Gland              Cast Iron               ASTM A126 CLB/JIS G 5501 FC20

8. Packing                        Graphite

9. Stem Nut                      Ductile Iron            ASTM A536 65-45-12/JIS G 5502 FCD450

10. Yoke                           Cast Iron                ASTM A126 CLB/JIS G 5501 FC20

11. Gasket                        Graphite



China Gate Valves Metal Sealed Types Of Gate Valves,TJL indusry group is a professional China valve manufacturer, Provide China Gate Valves, Welcome to contact us by Email:info@tjlindustry.com
