Socket Rising Stem Resilient Seat Gate Valve

Socket Gate Valve Product Overview

The groove type elastic seat gate valve is a new generation of valves connected by a clamp. It has the advantages of simple installation, meterial saving, fast, and easy maintenance of pipeline valves. Widely used in water supply and drainage, fire fighting, air conditioning, chemical industry, water treatment, municipal engineering,etc.

Socket Gate Valve Product Features

1.Light weight: This valve is made by ductile iron in resin sand shape, with high strength and low load, the weight of the valve is 20%~30% lower than a traditional gate valve, which can be installed and maintained very conveniently.

2.Plain seat: The seat of a traditional gate valve is normally hollow type that increases fluid resistance sily piles up sundries like welding slag, stone, mud and sand etc, which is bad for seal and fluid face. However, the resilient seated seal gate valve produced by our company  adopts a design of plain base type and straight through whole basin type which equals straigh pipes. It doesn't  easily pile up sundries, ensuring reliable seal and making fluid flow smoothly.

3.Disc overall packaged with rubber: The valve disc adopts high quality rubber to package itself overall both inside and outside, the European top-ranking rubber vulcanization technology can not only make vulcanized valve ensure precise dimensions but also make rubber and ductile iron wedge bond and coat tightly, not easily coming off and having good memory of resilience.

4.Disc overall packaged with rubber: The valve disc daopts high quality rubber to package itself overall both inside and outside, the European top-ranking rubber vulcanization technology can not only make vulcanized valve ensure precise dimensions but also make rubber and ductile iron wedge bond ang coat tightly, not easily coming off and having good memory of resilience,

5.Precise casting body: Body uses precise casting so that accurate dimensions can make body's inner part without any machining, ensuring good function of seal. Framework of the valce plate applies ductile iron, packaging with rubber overall, which owns accurate dimensions, tight bonding and coating, ang good memory of resilience. It is not coming off ang can interchange.

6.Anti-corrosion: The body's inside and outside adopt pulverous epoxy resin to do coating. The inner part uses stainless steel and copper alloy to prevent the corrosion and rusty, which can be used for sewage system and rusty, which can be used for sewage system and severe environment like underground.

7.Not easily crumbled: The traditional cast iron gate valve is normally caused to crumble by hitting, crashing and heavy pressing, etc. Use of ductile iron material, reduce most of such condition.

8.O ring seal ring: Body adopts the design of three layers of "O" type seal ring, which can reduce friction resistance caused by opening and closing, lessen leakage greatly and change the seal ring under the condition of water supply.

Socket Gate Valve Technical Parameters

Socket Gate Valve Main Part Materials

Socket Gate Valve Technical Parameters

Nominal pressure: 1.0~2.5MPA

Nominal diameter: 50-1200mm

Operating temperature: 0-80℃

Applicable media: Water and gas, etc

Flange standards: GB/T 17241.6、GB/T 9113、EN1092、ASME B16.5

Testing standards: GB/T 13927、API 598

Product Advantages

Superior Sealing and Fluid Flow

The resilient seat design of the valve ensures a smooth flow of fluids while maintaining a reliable seal, even under fluctuating pressures. This feature

helps to prevent leakage, which is especially crucial in applications where system integrity is vital. The valve’s ability to handle solid particulates without

 compromising its sealing efficiency makes it a trusted solution for systems where debris can be an issue.

Durability and Corrosion Resistance

Built with ductile iron and coated with pulverous epoxy resin, the Gate Valve offers exceptional corrosion resistance, making it highly suitable for use in

water and sewage systems, where rust and degradation are common issues. The materials used also provide excellent strength and resistance to wear,

 ensuring the valve operates reliably over an extended period with minimal maintenance.

Energy and Maintenance Efficiency

The Socket Rising Stem Gate Valve is designed for easy installation and low maintenance. Its light weight, 20% to 30% lower than traditional gate valves,

makes installation faster and more cost-effective. The valve’s components, including the O-ring seals and resilient rubber seat, ensure smooth operation

with reduced friction, thereby lowering the risk of valve failure and minimizing the need for maintenance.

About Us

TJL Industry Group Co., Ltd. is a prominent gate valve manufacturer, specializing in producing high-quality, durable valves for a variety of industrial

applications. With decades of experience, TJL is committed to providing reliable and cost-effective solutions for water treatment, chemical processing,

 oil and gas, and municipal infrastructure systems. Our gate valves, including the Socket Rising Stem Resilient Seat Gate Valve, are known for their

precision, durability, and outstanding performance in demanding environments. We pride ourselves on our stringent quality control standards, ensuring

 that all products meet international specifications. With our advanced manufacturing techniques and dedicated customer service, we continue to deliver

innovative valve solutions to industries around the world.

Contact us now for a reliable gate valve solution that suits your needs!

FAQ

What is the main benefit of the resilient seat design in this valve?

The resilient seat ensures a reliable seal, reduces fluid resistance, and prevents debris buildup, ensuring smooth fluid flow and reliable performance.

What materials are used in the construction of the valve?

The valve is made from ductile iron, with an epoxy resin coating for corrosion resistance. Stainless steel and bronze are used for key components like

the stem and bonnet.

What is the pressure rating for this valve?

The valve is rated for pressures between 1.0 to 2.5 MPa, making it suitable for a variety of industrial applications.

Can this valve be used in sewage systems?

Yes, the valve’s corrosion-resistant materials and robust design make it ideal for use in sewage and wastewater systems.

What temperature range can the valve handle?

The valve operates efficiently within a temperature range of 0-70°C, making it suitable for water, sewage, and raw water applications.
